Product Summary
The LT1585ACM-1.5 is a low dropout, 3-terminal regulator with 5A output current capability respectively, and a fixed 1.5V output voltage. The designs are optimized for low voltage applications where transient response and minimum input voltage are critical. Similar to the LT1084, the LT1585ACM-1.5 has lower dropout and faster transient response. These improvements make it ideal for low voltage microprocessor applications, especially as the regulator in an Intel processor GTL+ supply.The LT1585ACM-1.5 is designed for: GTL+ Power Supply, Low Voltage Logic Supplies and Battery-Powered Circuitry.
Parametrics
LT1585ACM-1.5 absolute maximum ratings: (1)VIN: 7V; (2)Operating Junction Temperature Range: Control Section: 0℃ to 125℃; Power Transistor: 0℃ to 150℃; (3)Storage Temperature Range: – 65℃ to 150℃; (4)Lead Temperature (Soldering, 10 sec): 300℃.
Features
LT1585ACM-1.5 features: (1)Fast Transient Response; (2)Guaranteed Dropout Voltage at Multiple Currents; (3)Load Regulation: 0.05% Typ; (4)Trimmed Current Limit; (5)On-Chip Thermal Limiting.
Diagrams
Image | Part No | Mfg | Description | Pricing (USD) |
Quantity | |||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|
LT1585ACM-1.5 |
IC REG LDO 1.5V DDPAK-3 |
Data Sheet |
|
|
||||||||
LT1585ACM-1.5#PBF |
IC REG LDO 1.5V DDPAK-3 |
Data Sheet |
|
|
||||||||
LT1585ACM-1.5#TR |
IC REG LDO 1.5V DDPAK |
Data Sheet |
|
|
||||||||
LT1585ACM-1.5#TRPBF |
IC REG LDO 1.5V DDPAK-3 |
Data Sheet |
|
|
