Product Summary

The SIS756 is a HyperTransport to PCIe / MuTIOL Bridge, which integrates a high performance HyperTransport interface for the AMD Athlon 64 X2 Dual-Core processor and Athlon 64 FX processor family, the PCI Express x16 interface, and SiS MuTIOL Technology, which connects with the SiS965/965L MuTIOL Media IO. The HyperTransport interface of the SIS756 features HyperTransport complaint bus driver technology to support AMD Athlon 64 X2 / Athlon 64 FX processors of up to 2000MT/s data rate.

Features

SIS756 features: (1)Integrated Giga MAC Controller with Standard MII/GMII/RGMII Interface; (2)Serial ATA Controller; (3)Four Independent ports with Ultra DMA 150 support; (4)IDE Controller; (5)Dual Independent IDE Channels with ATA133/100/66 support; (6)PCI-Express x1; (7)Two PCI-Express x 1 ports for devices; (8)USB 2.0 /1.1 Support; (9)Support a maximum of 8 USB Ports. Dynamic connection to USB 1.1 or USB 2.0.; (10)Integrated Audio Controller w/ AC97 2.3 Compliance Interface; (11)Support 8 channel of Audio output and V.90 HSP Modem; (12)PCI 2.3 Compliant; (13)Support up to 6 PCI Masters; (14)LPC Interface 1.1 Compliance; (15)ACPI 2.0 Compliance; (16)I/O APIC Support; (17)PC2001 Compliance; (18)SiS MuTIOL Technology Delivering 1GB/sec Bandwidth.

Diagrams

SIS756 circuit diagram

SiS778DN-T1-GE3
SiS778DN-T1-GE3
Vishay/Siliconix
MOSFET 30 Volts 35 Amps 52 Watts
Data Sheet
0-2000: $0.19
2000-3000: $0.18
3000-6000: $0.17
6000-12000: $0.16
SiS780DN-T1-GE3
SiS780DN-T1-GE3
Vishay/Siliconix
MOSFET 30 Volts 18 Amps 27.7 Watts
Data Sheet
0-1: $0.26
1-10: $0.25
10-100: $0.19
100-250: $0.16
SiS782DN-T1-GE3
SiS782DN-T1-GE3
Vishay/Siliconix
MOSFET 30 Volts 16 Amps 41 Watts
Data Sheet
0-1: $0.29
1-10: $0.28
10-100: $0.20
100-250: $0.17
