Product Summary
The OPA333AIDCKR CMOS operational amplifiers uses a proprietary auto-calibration technique to simultaneously provide very low offset voltage (10 mV max) and near-zero drift over time and temperature. This miniature, high-precision, low-quiescent-current amplifiers offer high-impedance inputs that have a common-mode range 100 mV beyond the rails, and rail-to-rail output that swings within 50 mV of the rails. Single or dual supplies as low as 1.8 V (±0.9 V) and up to 5.5 V (±2.75 V) may be used. They are optimized for low-voltage single supply operation. The OPA333AIDCKR family offers excellent common-mode rejection ratio (CMRR) without the crossover associated with traditional complementary input stages. This design results in superior performance for driving analog-to-digital converters (ADCs) without degradation of differential linearity. The OPA333AIDCKR (single version) is available in the SC70-5 and SOT23-5 packages. The OPA333AIDCKR (dual version) is offered in the SO-8 package. All versions are specified for operation from –55℃ to 125℃.
Parametrics
Absolute maximum ratings:(1)Supply voltage: 7V; (2)Signal input terminals, voltage: –0.3 to (V+)+0.3V; (3)Output short circuit: Continuous; (4)Operating temperature range: –55 to 125℃; (5)Storage temperature range: –65 to 150℃; (6)Junction temperature: 150℃; (7)ESD rating Human-Body Model (HBM): 4000V; (8)Charged-Device Model (CDM): 1000V.
Features
Features: (1)Low Offset Voltage: 23 μV (Max); (2)0.01-Hz to 10-Hz Noise: 1.1 μVPP; (3)Quiescent Current: 17 μA; (4)Single-Supply Operation; (5)Supply Voltage: 1.8 V to 5.5 V; (6)Rail-to-Rail Input/Output; (7)MicroSize Packages: SC70 and SOT23.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 OPA333AIDCKR |
Texas Instruments |
Operational Amplifiers - Op Amps 1.8V 17uA 2uV microPOWER CMOS |
Data Sheet |
|
|
||||||||||||
|
OPA333AIDCKRG4 |
Texas Instruments |
Operational Amplifiers - Op Amps 1.8V 17uA 2uV microPOWER CMOS |
Data Sheet |
|
|
||||||||||||
