Product Summary

The TPS60110PWP is a regulated 5V 300mA low-noise charge pump DC/DC converter. The applications of it include: (1)Battery-Powered Applications; (2)Li-Ion Battery to 5-V Conversion; (3)Portable Instruments; (4)Battery-Powered Microprocessor Systems; (5)Miniature Equipment; (6)Backup-Battery Boost Converters; (7)PDAs; (8)Laptops; (9)Handheld Instrumentation; (10)Medical Instruments.

Parametrics

TPS60110PWP absolute maxing ratings: (1)Input voltage range, VI (IN, OUT, ENABLE, SKIP, COM, CLK, FB, SYNC): -0.3 V to 5.5 V; (2)Differential input voltage, VID (C1+, C2+ to GND): -0.3 V to (VO + 0.3 V); (3)Differential input voltage, VID (C1–, C2– to GND): -0.3 V to (VIN + 0.3 V); (4)Continuous output current: 400 mA; (5)Storage temperature range, Tstg: -55℃ to 150℃; (6)Lead temperature 1,6 mm (1/16 inch) from case for 10s: 260℃; (7)Maximum junction temperature, TJ: 150℃.

Features

TPS60110PWP features: (1)Up to 300-mA Output Current; (2)Less Than 10-mVpp Output Voltage Ripple; (3)No Inductors Required/Low EMI; (4)Regulated 5-V ±4% Output; (5)Only Four External Components Required; (6)Up to 90% Efficiency; (7)2.7-V to 5.4-V Input Voltage Range; (8)60-μA Quiescent Supply Current; (9)0.05-μA Shutdown Current; (10)Load Isolated in Shutdown.

Diagrams

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
TPS60110PWP
TPS60110PWP
Texas Instruments
Charge Pumps Reg 5V Lo-Ns Charge Pump DC-DC Cnvtr
Data Sheet
0-1: $1.63
1-25: $1.48
25-100: $1.19
100-250: $1.03
TPS60110PWPRG4
TPS60110PWPRG4
Texas Instruments
Charge Pumps Reg 5V Lo-Ns Charge Pump DC-DC Cnvtr
Data Sheet
0-1430: $0.76
1430-2000: $0.72
2000-5000: $0.69
5000-10000: $0.67
TPS60110PWPR
TPS60110PWPR
Texas Instruments
Charge Pumps Reg 5V Lo-Ns Charge Pump DC-DC Cnvtr
Data Sheet
0-1: $1.51
1-25: $1.22
25-100: $1.10
100-250: $1.00
TPS60110PWPG4
TPS60110PWPG4
Texas Instruments
Charge Pumps Reg 5V Lo-Ns Charge Pump DC-DC Cnvtr
Data Sheet
0-1: $1.60
1-25: $1.35
25-100: $1.17
100-250: $1.03
