Product Summary

The AD712JRZ-REEL7 is a high speed, precision, monolithic operational amplifier offering high performance at very modest prices. Its very low offset voltage and offset voltage drift are the results of advanced laser wafer trimming technology. These performance benefits allow the user to easily upgrade existing designs that use older precision BiFETs and, in many cases, bipolar op amps. The superior ac and dc performance of this op amp makes it suitable for active filter applications. With a slew rate of 16 V/μs and a settling time of 1 μs to ±0.01%, the AD712JRZ-REEL7 is ideal as a buffer for 12-bit digital-to-analog and analog-to-digital converters and as a high speed integrator. The settling time is unmatched by any similar IC amplifier.

Parametrics

AD712JRZ-REEL7 absolute maximum ratings: (1)Supply Voltage ±18 V; (2)Internal Power Dissipation. Input Voltage ±18 V; (3)Output Short-Circuit Duration Indefinite; (4)Differential Input Voltage +VS and .VS; (5)Storage Temperature Range Q-Suffix -65℃ to +150℃; (6)N-Suffix and R-Suffix -65℃ to +125℃; (7)Lead Temperature Range (Soldering 60 sec) 300℃.

Features

AD712JRZ-REEL7 features: (1)Enhanced replacement for LF412 and TL082; (2)200 V/mV minimum open-loop gain (AD712K); (3)Surface mount available in tape and reel in accordance with the EIA-481A standard; (4)MIL-STD-883B parts available; (5)Single version available: AD711; (6)Quad version: AD713; (7)Available in PDIP, SOIC_N, and CERDIP packages.

Diagrams

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
AD712JRZ-REEL7
AD712JRZ-REEL7


IC OPAMP BIFET DUAL PREC 8SOIC

Data Sheet

0-750: $1.40
750-1500: $1.31
1500-2250: $1.25
