Product Summary
The APE30012 is a kind of slim power relay. It is designed for: (1)Interface relays for programmable controllers; (2)Output relays for measuring equipment, timers, counters and; (3)temperature controllers; (4)Industrial equipment, office equipment; (5)House-hold appliances for Europe.
Parametrics
APE30012 absolute maximum ratings: (1)Nominal coil voltage: 12V DC; (2)Pick-up voltage (at 20°C 68°F): 66%V or less of nominal voltage (Initial); (3)Drop-out voltage (at 20°C 68°F): 5%V or more of nominal voltage (Initial); (4)Nominal operating current (at 20°C 68°F): 14mA; (5)Coil resistance (at 20°C 68°F): 847Ω; (6)Nominal operating power: 170mW; (7)Max. allowable voltage (at 20°C 68°F): 120%V of nominal voltage.
Features
APE30012 features: (1)5 mm width allows high density mounting; (2)Satisfies insulation distance standard (VDE0700: household devices); (3)High capacity of 6A; (4)1 Form A and 1 Form C contact arrangements available; (5)4,000 V high breakdown voltage and 6,000 V high surge breakdown voltage; (6)Sealed construction allows automatic washing; (7)Complies with all safety standards.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 APE30012 |
Panasonic Electric Works |
General Purpose / Industrial Relays 6A 12VDC SPDT SILVER PCB |
Data Sheet |
Negotiable |
|
||||||||||||
| Image | Part No | Mfg | Description | |
Pricing (USD) |
Quantity | ||||||||||||
|
APE30006 |
Panasonic Electric Works |
General Purpose / Industrial Relays 1 Form A 6A 6V Silver Alloy Contact |
Data Sheet |
Negotiable |
|
||||||||||||
|
APE30012 |
Panasonic Electric Works |
General Purpose / Industrial Relays 6A 12VDC SPDT SILVER PCB |
Data Sheet |
Negotiable |
|
||||||||||||
|
APE30018 |
Panasonic Electric Works |
General Purpose / Industrial Relays 1 Form A 6A 18V Silver Alloy Contact |
Data Sheet |
|
|
||||||||||||
|
APE30024 |
Panasonic Electric Works |
General Purpose / Industrial Relays 6A 24VDC SPDT SILVER PCB |
Data Sheet |
Negotiable |
|
||||||||||||
|
APE30048 |
Panasonic Electric Works |
General Purpose / Industrial Relays 1 Form A 6A 48V Silver Alloy Contact |
Data Sheet |
|
|
||||||||||||
|
APE3004H |
Panasonic Electric Works |
General Purpose / Industrial Relays 1 Form A 6A 4.5V Silver Alloy Contact |
Data Sheet |
|
|
||||||||||||
