LM2793LDX

LM2793LDX, 10-LLP, dual constant current output, QFN, -0.3V to 6.0V

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.48~0.52 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.48~0.52

PartNumber:: LM2793LDX

Brand:: National Semiconductor - NS | Pack: QFN | D/C: 05+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Sophia's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-11-15

From Other Seller

Part Number:LM2793LDX
US $0.48 - 0.52
ECA1HHG100

US $10.00 - 10.00 / Piece
(0) Remove
IRFP260N

US $1.30 - 4.20 / Piece
(0) Remove
Quantity:

piece

Product Summary

The LM2793LDX is a highly efficient, semi-regulated 1.5x CMOS charge pump that provides dual constant current outputs. The LM2793LDX has an input voltage range of 2.7V to 5.5V. To control LED brightness, the amount of current driven to the current-mode outputs can be adjusted with an analog voltage and/or a pulse-width-modulated (PWM) square wave. Pre-regulation of the charge pump minimizes conducted noise on the input. Combined with a fixed switching frequency of 500kHz, the LM2793LDX is a low-noise solution. The LM2793LDX is available in a 10-pin Leadless Lead-frame package: LLP-10.

Parametrics

LM2793LDX absolute maximum ratings: (1)VIN: -0.3V to 6.0V; (2)VSD-BRGT: -0.3V to (VIN + 0.3V) w/ 6.0V max; (3)Continuous Power Dissipation: Internally Limited; (4)Junction Temperature (TJ-MAX-ABS): 150℃; (5)Storage Temperature Range: -65℃ to 150℃; (6)Lead Temp. (Soldering, 5 sec.): 260℃; (7)Junction-to-Ambient Thermal Resistance, LLP-10 Package (θJA): 55℃/W.

Features

LM2793LDX features: (1)Two Regulated Current Outputs, up to 16mA Each, Matched to Within ±0.3% (typ.); (2)High Efficiency, 1.5x Regulated Charge Pump; (3)Input Voltage Range: 2.7V to 5.5V; (4)Soft Start Limits Inrush Current; (5)Analog Voltage Brightness Control; (6)PWM Brightness Control; (7)Very Small Solution Size - NO INDUCTOR; (8)500kHz Switching Frequency; (9)3μA (typ.) Shutdown Current; (10)LLP-10 Package: 3.0mm X 3.0mm X 0.8mm.
