Product Summary

The MDC200A1600V is a diode module. The applications of the MDC200A1600V include Supplies for DC power equipment, DC supply for PWM inverter, Field supply for DC motors, Battery DC power supplies.

Parametrics

MDC200A1600V absolute maximum ratings: (1)IFRMS: 180A; (2)IF(AV) when TC=105℃, 180℃ sine: 120A; (3)IFSM when TVJ=45℃, t = 10ms(50Hz), sine: 2800A; (4)IR when TVJ = TVJM, VR = VRRM: 15mA; (5)VF when IF = 300A, TVJ=25℃: 1.43V; (6)TVJ: -40℃ to +150℃; (7)TVJM: 150℃; (8)TSTG: -40℃ to +125℃.

Features

MDC200A1600V features: (1) Space and weight savings; (2) Simple mounting; (3) Improved temperature and power cycling; (4) Reduced protection circuits.

Diagrams

MDC200A1600V dimension
