Product Summary
The SI6544BDQ-TI-E3 is an N-and P-Channel 30-V (D-S) MOSFET.
Parametrics
SI6544BDQ-TI-E3 absolute maximum ratings: (1)Continuous Source Current (Diode Conduction)a IS 1~0 0.7; (2)Maximum Power Dissipationa TA = 25℃ PD: 1.14~0.83W; (3)TA = 70℃ 0.73~0.53; (4)Operating Junction and Storage Temperature Range TJ, Tstg:-55 to 150 ℃; (5)Drain-Source Voltage VDS: 30 -30V; (6)Gate-Source Voltage VGS: 20.
Features
SI6544BDQ-TI-E3 features: (1)TrenchFET Power MOSFETS.
Diagrams
 |
