Product Summary
The LCMX01200C-3FTN256C is a BGA single chip. It is optimized to meet the requirements of applications traditionally addressed by CPLDs and low capacity FPGAs: glue logic, bus bridging, bus interfacing, power-up control, and control logic. The LCMX01200C-3FTN256C brings together the best features of CPLD and FPGA devices on a single chip.
Parametrics
LCMX01200C-3FTN256C absolute maximum ratings: (1)Supply Voltage VCC: -0.5V to 3.75V; (2)Supply Voltage VCCAUX: -0.5V to 3.75V; (3)Output Supply Voltage VCCIO: -0.5V to 3.75V; (4)I/O Tristate Voltage Applied 4: -0.5V to 3.75V; (5)Dedicated Input Voltage Applied4: -0.5V to 4.25V; (6)Storage Temperature (ambient): -65℃ to 150℃; (7) Junction Temp. (Tj): +125℃.
Features
LCMX01200C-3FTN256C features: (1)Non-volatile, Infinitely Reconfigurable; (2)Sleep Mode: Allows up to 100x static current reduction; (3)TransFR Reconfiguration (TFR): In-field logic update while system operates; (4)High I/O to Logic Density; (5)Embedded and Distributed Memory; (6)Flexible I/O Buffer; (7)sysCLOCK PLLs; (8)IEEE Standard 1149.1 Boundary Scan; (9)Onboard oscillator; (10)Devices operate with 3.3V, 2.5V, 1.8V or 1.2V power supply; (11)IEEE 1532 compliant in-system programming.
