Product Summary

The chip ferrite bead BLM31AJ260SN1 comprises ferrite beads in the shape of a chip. This ferrite bead generates a high impedance which at high frequency mainly consists of a resistance element. The BLM31AJ260SN1 is effective in circuits without stable ground lines because the BLM31AJ260SN1 does not need a connection to ground. The nickel barrier structure of the external electrodes provides excellent solder heat resistance. BLM31AJ260SN1 generates an impedance from the relatively low frequencies. Therefore BLM31AJ260SN1 is effective in noise suppression in a wide frequency range (30MHz - several hundred MHz). The small size of BLM31AJ260SN1 (0.6x0.3mm) is suitable for noise suppression in small equipment such as PA modules for cellular phones.

Parametrics

BLM31AJ260SN1 absolute maximum ratings: (1)Impedance: 80ohm ±25%; (2)Rated Current: 500mA; (3)DC Resistance (max.): 0.10 ohm; (4)Operating; (5)Temperature Range: -55 to 125℃.

Features

BLM31AJ260SN1 features: (1)The chip ferrite bead comprises ferrite beads in the shape of a chip; (2)This ferrite bead generates a high impedance which at high frequency mainly consists of a resistance element ; (3)Effective in circuits without stable ground lines; (4)Does not need a connection to ground; (5)Excellent solder heat resistance ; (6)BLM31AJ260SN1 generates an impedance from the relatively low frequencies; (7)Effective in noise suppression in a wide frequency range (30MHz - several hundred MHz) ; (8)Small size (0.6x0.3mm) is suitable for noise suppression in small equipment such as PA modules for cellular phones.

Diagrams

BLM31AJ260SN1 Equivalent Circuit
