Product Summary
The LM285BYMX-2.5 is a micropower 3-terminal adjustable band-gap voltage reference diode. Operating from 1.24 to 5.3V and over a 10μA to 20mA current range, the LM285BYMX-2.5 features exceptionally low dynamic impedance and good temperature stability. On-chip trimming is used to provide tight voltage tolerance. Since the LM185 band-gap reference uses only transistors and resistors, low noise and good long-term stability result. The LM285BYMX-2.55 is rated -40℃ to 85℃. The LM285BYMX-2.55 is available in a low-cost TO-92 molded package, as well as S.O.
Parametrics
LM285BYMX-2.5 absolute maximum ratings: (1)Reverse Current: 30mA; (2)Forward Current: 10mA; (3)Operating Temperature Range: -40℃ to 85℃; (4)ESD Susceptibility: 2kV; (5)Storage Temperature: 55℃ to 150℃; (6)Soldering Information (10 sec.): 260℃.
Features
LM285BYMX-2.5 features: (1)Adjustable from 1.24V to 5.30V; (2)Operating current of 10μA to 20mA; (3)1% and 2% initial tolerance; (4)1Ω dynamic impedance; (5)Low temperature coefficient.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 LM285BYMX-2.5 |
National Semiconductor (TI) |
Voltage & Current References |
Data Sheet |
|
|
||||||||||
|
LM285BYMX-2.5/NOPB |
National Semiconductor (TI) |
Voltage & Current References |
Data Sheet |
|
|
||||||||||
