MAAL-008091-TR3000

High Dynamic Range, Low Noise Amplifier, 800 - 1000 MHz, SOP8, 1.2 dB, 20 to 80 mA

Rated 5 Rating 5 | reviews | Write a review

Price:: US $1.00~2.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $1.00~2.00

PartNumber:: MAAL-008091-TR3000

Brand:: M/A-COM Technology Solutions Inc. - MACOM | Pack: SOP | D/C: 08+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Sophia's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-06-29

From Other Seller

Part Number:MAAL-008091-TR3000
US $1.00 - 2.00
EKXG401ELL6R8MJ16S

US $5.00 - 5.00 / Piece
(0) Remove
ad7716ap

US $1.13 - 1.13 / Piece
(0) Remove
Quantity:

piece

Product Summary

The MAAL-008091-TR3000 is a high dynamic range, GaAs MMIC, low noise amplifier in a lead-free SOIC-8, surface mount plastic package. It employs external input matching to obtain optimum noise figure performance and operating frequency flexibility. The MAAL-008091-TR3000 also features flexible biasing to control the current consumption vs. dynamic range trade-off. The MAAL-008091-TR3000 can operate from any supply voltage in the 3 V to 8 V range. Its current can be controlled over a range of 20 mA to 80 mA with an external resistor. The MAAL-008091-TR3000 is ideally suited for use where low noise figure, high gain, high dynamic range, and low power consumption are required. Typical applications include receiver front ends in AMPS, GSM, and ETACS base stations. It is also useful as a gain block, buffer, driver, and IF amplifier in both fixed and portable cellular and 900 MHz ISM systems.

Parametrics

MAAL-008091-TR3000 absolute maximum ratings: (1)VDD: +10 VDC; (2)Input Power: +10 dBm; (3)Current: 120 mA; (4)Channel Temperature: +150℃; (5)Operating Temperature: -40℃ to +85℃; (6)Storage Temperature: -65℃ to +150℃.

Features

MAAL-008091-TR3000 features: (1)Low Noise Figure: 1.2 dB; (2)High Input IP3: +18 dBm at 8 V, 60 mA bias; (3)+6.5 dBm at 3 V, 20 mA bias; (4)High Gain: 15 dB; (5)Single Supply: +3 to +8 VDC; (6)Adjustable current: 20 to 80 mA with external resistor; (7)Lead-Free SOIC-8 Package; (8)100% Matte Tin Plating over Copper; (9)Halogen-Free Green Mold Compound; (10)260℃ Reflow Compatible; (11)RoHS Compliant Version of AM50-0003.
