Product Summary

The SK150DB100D is a miniature schottky barrier rectifier.

Parametrics

SK150DB100D absolute maximum ratings: (1)Maximum Recurrent Peak Reverse Voltage: 50Volts; (2)Maximum RMS Voltage: 35Volts; (3)Maximum DC Blocking Voltage: 50Volts ; (4)Maximum Average Forward Rectified Output .375" (9.5mm) lead length: 1.0A; (5)Peak Forward Surge Current, 8.3 ms single half sine-wave superimposed on rated load (JEDEC method): 40A; (6)Typical Thermal Resistance: 50℃/W; (7)Typical Junction Capacitance: 110pF; (8)Operating Temperature Range: -65℃ to +150℃; (9)Storage and Operating Temperature Range: -65℃ to +150℃.

Features

SK150DB100D features: (1)Low switching noise; (2)Low forward voltage drop; (3)High current capability; (4)High switching capability; (5)High reliability; (6)High surge capability.

Diagrams

SK150DB100D dimension
